SCREEN PRINTING ON GLASS

Silk-screening ceramic frit onto glass is an excellent way for architects and designers to create exciting new looks on their projects using patterns and colours. Silk-screened glass improves solar control performance and can be used on various glass substrates, including clear, low-iron or tinted glass, to reduce glare and decrease solar transmission. Depending on which pattern, color of ceramic frit and glass substrate you select, glass panels will either be transparent, translucent or opaque. The process of silk-screening uses a patterned screen to transfer ceramic frit onto the surface of the glass. The ceramic frit is then fused onto the surface of the glass during the toughening or heat strengthening process, creating a permanent bond to the glass surface.

Technical Specification

FEATURE DESCRIPTION
Process Type HS - SEL Glass printing - Horizontal Silk Screen Printing
Glass Types Clear, Extra Clear, Ultra Clear, Low Iron, Tinted, Hard Coated
Additional Process Compatibility Safety Glazing(Tempered & Laminated) & Insulated Glass Unit
Product Enhancement Can be converted into Single Glass Unit, Laminated Glass Unit, Insulated Glass Unit
Glass Thickness 4mm To 19mm
Edge Types Rough Grind, Matt Finish, Polished
Dimensions Minimum Size = 600mm X 400mm
Maximum Size = 3700mm X 2100mm
